APC - APC Smart-UPS On-Line
UPS (rack-mountable / external) - NEMA 5-15R outlets, network card, extended runtime, rail kit - AC 120 V - 900 Watt - 1000 VA - 1-phase - USB, serial, Ethernet 10/100/1000 - output connectors: 6 - 2U - 6 ft cord - black - APC Take-Back - TAA Compliant
APC
SRT1000RMXLA-NCUS
0731304740568
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | APC Smart-UPS On-Line - UPS - NEMA 5-15R outlets, network card, extended runtime, rail kit - 900 Watt - 1000 VA - TAA Compliant |
| Device Type | UPS - rack-mountable / external |
| Cord Length | 6 ft |
| Rack Size | 2U |
| Weight | 48.5 lbs |
| Input Wiring | 1-phase |
| Input Voltage | AC 120 V |
| Output Voltage | AC 120 V |
| Power Capacity | 900 Watt / 1000 VA |
| Input Connectors | 1 x power NEMA 5-15P |
| Output connectors | 6 x power NEMA 5-15R |
| Battery | Lead acid |
| Run Time (Up To) | 10.5 min at full load |
| Networking | USB, serial, Ethernet 10/100/1000 |
| Color | Black |
| Pricing Type | APC Take-Back |
| TAA Compliant | Yes |
| Dimensions (WxDxH) | 17 in x 20 in x 3.3 in |
| Environmental Standards | ENERGY STAR |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Device Type | UPS - rack-mountable / external |
| Height (Rack Units) | 2U |
| Cord Length | 6 ft |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 1 x serial - RJ-45 ¦ 1 x management (Gigabit Ethernet) - RJ-45 ¦ 3 x USB - 4 pin USB Type A ¦ 2 x universal I/O port ¦ 1 x console - Micro-USB Type B |
| Expansion Slots | 1 (total) / 0 (free) x SmartSlot |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - replace or repair - 3 years ¦ Limited warranty - battery - 2 years |
| Miscellaneous | |
| Cables Included | Power cable 6 ft |
| Rack Mounting Kit | Included |
| Features | Horizontal mount, extended runtime, double conversion, LCD display, audible alarm, visible alarm, emergency power off, built-in static bypass |
| Compliant Standards | RoHS, REACH SvHC, IP20 |
| Pricing Type | APC Take-Back |
| TAA Compliant | Yes |
| Networking | |
| Remote Management Interface | USB, serial, Ethernet 10/100/1000 |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Sound Emission | 50 dBA |
| Battery | |
| Technology | Lead acid |
| Voltage Provided | 48 V |
| Run Time (Up To) | 10.5 min at full load ¦ 25.4 min at half load |
| Recharge Time | 3 hours |
| Power Device | |
| UPS Technology | On-line |
| Input Voltage | AC 120 V |
| Frequency Provided | 50/60 Hz ± 3Hz |
| Input Wiring | 1-phase |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Power Output Connectors Details | 6 x power NEMA 5-15R |
| Output Voltage | AC 120 V 50/60 Hz |
| Power Capacity | 900 Watt / 1000 VA |
| Output Waveform | Sinewave |
| Surge Suppression | Yes |
| Surge Energy Rating | 432 Joules |
| Efficiency | 92.3% at 100% Load, 91.6% at 75% Load, 89.9% at 50% Load, 84.3% at 25% Load |
| Total Harmonic Distortion (THD) | 2 % |
| Dimensions & Weight | |
| Width | 17 in |
| Depth | 20 in |
| Height | 3.3 in |
| Weight | 48.5 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 29.5 in |
| Shipping Depth | 23.4 in |
| Shipping Height | 9.7 in |
| Shipping Weight | 65.26 lbs |
| Sustainability Information | |
| ENERGY STAR | Yes |
