Axis Communications - AXIS Q2101-TE
Thermal network camera - bullet - outdoor - vandal / weatherproof - 384 x 288 - audio - GbE - MJPEG, H.264, H.265 - DC 8 - 28 V / PoE+ - TAA Compliant
Axis Communications
02650-001
7331021081086
N/A
New
Price: $4,249.15
MSRP: $4,999.00
Discount off MSRP: 15.00%
Total Available: 0
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | AXIS Q2101-TE - thermal network camera - bullet - TAA Compliant |
| Device Type | Thermal network camera - fixed - bullet - outdoor - vandal / weatherproof |
| Audio | Yes: two-way audio via edge-to-edge technology |
| Dimensions (WxDxH) | 6.3 in x 15.9 in x 5.9 in |
| Weight | 7.28 lbs |
| Color | White, NCS S 1002-B |
| Connectivity Technology | Wired |
| Max Resolution | 384 x 288 |
| Frame Rate (max) | 30 frames per second |
| Motion Detection | Yes |
| Focal Length | 7 mm |
| Focus Adjustment | Athermalized (min distance 4.3 ft) |
| Lens Iris | F/1.18 |
| Interfaces | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Voltage | DC 8 - 28 V / PoE+ |
| Features | 256 preset positions, uncooled micro bolometer, thermal sensitivity 40 mK (NETD), deep learning processing unit (DLPU), Zipstream technology, Multi-Bitrate (MBR), Variable Bitrate (VBR), Adaptive Bitrate (ABR), video streaming indicator, 180° image rotation, 270° image rotation, 90° image rotation, brightness control, contrast control, sharpness control, auto AGC, full duplex audio, half duplex audio, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, electronic image stabilization, image overlay, dynamic text overlay, polygon privacy mask, multiple color palettes, NAS-Ready, Audio Detection, active tampering alarm, -40 °C to 350 °C object temperature monitoring |
| TAA Compliant | Yes |
| Manufacturer Warranty | 5-year warranty |
| Environmental Parameters (operating) | -40 °F - 140 °F; 10 - 100% RH (condensing) relative humidity |
| General | |
| Device Type | Thermal network camera |
| Audio Support | Yes: two-way audio via edge-to-edge technology |
| Audio Formats | LPCM, AAC-LC, G.711, G.726, ADPCM, OPUS |
| Form Factor | Bullet |
| Connectivity Technology | Wired |
| Width | 6.3 in |
| Depth | 15.9 in |
| Height | 5.9 in |
| Weight | 7.28 lbs |
| Localization | United States, United Kingdom, Japan, European Union, China, Brazil, Australia, Argentina |
| Expansion / Connectivity | |
| Ports | LAN/power - RJ-45 ¦ Audio line in - 3.5 mm jack ¦ Serial RS-485/RS-422 - terminal block |
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| Encryption Algorithm | EAP-TLS, PEAP, MSCHAPv2, TLS 1.2, TLS 1.3, FIPS 140-2 Level 2 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Included Accessories | Torx T30 screw bit, Torx T20 screw driver, terminal block connectors, connector guard, cable gaskets, owner authentication key |
| TAA Compliant | Yes |
| Compliant Standards | CSA, UL, cUL, UKCA, KC, RCM, CISPR 35, CISPR 32 Class A, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, IEC 62236-4, AS/NZS CISPR 32 Class A, ICES-3(A)/NMB-3(A), VCCI Class A, KS C 9835, KS C 9832 Class A, FCC Part 15 B Class A, CAN/CSA C22.2 No. 62368-1 Third Edition, IEC/EN/UL 62368-1, IS 13252, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 60529 IP67, IEC/EN 62262 IK10, ISO 21207 method B, MIL-STD-810H, NEMA250 Type 4X, NEMA TS-2 (2.2.7-2.2.9), NIST SP500-267, ETSI EN 303 645, IEEE 802.1x, IEEE 802.1ar, IEEE 802.1ae, X.509, BFR-free, CFR free, PVC-free, JEDEC, ECA, EN 63000:2018, REACH 1907/2006/CE, RoHS 2011/65/EU |
| Color | White, NCS S 1002-B |
| Power | |
| Power Requirements | DC 8 - 28 V / PoE+ |
| Power Device | 4.1 Watt |
| Environmental Parameters | |
| Min Operating Temperature | -40 °F |
| Max Operating Temperature | 140 °F |
| Relative Humidity (operating) | 10 - 100% RH (condensing) |
| Camera | |
| Type | - fixed - outdoor - vandal / weatherproof |
| Digital Video Format | MJPEG, H.264, H.265 |
| Max Digital Video Resolution | 384 x 288 |
| Motion Detection | Yes |
| Frame Rate (max) | 30 frames per second |
| RAM | 2 GB |
| Flash Memory | 8 GB |
| Features | 256 preset positions, uncooled micro bolometer, thermal sensitivity 40 mK (NETD), deep learning processing unit (DLPU), Zipstream technology, Multi-Bitrate (MBR), Variable Bitrate (VBR), Adaptive Bitrate (ABR), video streaming indicator, 180° image rotation, 270° image rotation, 90° image rotation, brightness control, contrast control, sharpness control, auto AGC, full duplex audio, half duplex audio, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, electronic image stabilization, image overlay, dynamic text overlay, polygon privacy mask, multiple color palettes, NAS-Ready, Audio Detection, active tampering alarm, -40 °C to 350 °C object temperature monitoring |
| Lens Construction | |
| Focal Length | 7 mm |
| Lens Iris | F/1.18 |
| Focus Adjustment | Athermalized |
| Min Focus Distance | 4.3 ft |
| Horizontal Field of View (degree) | 55 |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | IPv4, IPv6, USGv6, ICMP, HTTPS, HTTP, TLS, QOS, FTP, SFTP, CIFS, SMB, SMTP, MDNS, Bonjour, UPnP, SNMP, DNS, DDNS, NTP, NTS, RTSP, RTP, SRTP, TCP/IP, UDP/IP, IGMP, RTCP, DHCP, SSH, LLDP, CDP, MQTT, Syslog, Zeroconf |
| Alarm Inputs Qty | 2 |
| Alarm Outputs Qty | 2 |
