APC - APC NetShelter
Automatic transfer switch (rack-mountable) - AC 207-253 V - 7400 VA - 1-phase - Ethernet 10/100/1000, USB - output connectors: 18 - 2U - 8 ft cord - black
APC
AP4424A
0731304432456
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | APC NetShelter - automatic transfer switch - 7400 VA |
| Device Type | Automatic transfer switch - rack-mountable |
| Cord Length | 8 ft |
| Rack Size | 2U |
| Weight | 15.3 lbs |
| Input Wiring | 1-phase |
| Input Voltage | AC 207-253 V |
| Output Voltage | AC 230 V |
| Power Capacity | 7400 VA |
| Input Connectors | 2 x power IEC 60309 32A |
| Output connectors | 16 x power IEC 60320 C13 ¦ 2 x power IEC 60320 C19 |
| Networking | Ethernet 10/100/1000, USB |
| Included Accessories | Mounting kit, rack mounting brackets, serial configuration cable |
| Color | Black |
| Dimensions (WxDxH) | 17 in x 9.3 in x 3.5 in |
| Manufacturer Warranty | 2-year warranty |
| General | |
| Device Type | Automatic transfer switch - rack-mountable |
| Height (Rack Units) | 2U |
| Cord Length | 8 ft |
| Color | Black |
| Expansion / Connectivity | |
| Interfaces | 4 x LAN - RJ-45 ¦ 1 x USB - 4 pin USB Type A ¦ 1 x USB - 5 pin Micro-USB Type B |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - replace or repair - 2 years |
| Miscellaneous | |
| Included Accessories | Mounting kit, rack mounting brackets, serial configuration cable |
| Cables Included | 2 x serial cable - external - 8 ft |
| Rack Mounting Kit | Included |
| Features | Horizontal mount, mercury free, LED indicators, LCD display |
| Compliant Standards | EN 55022 Class A, FCC Part 15 A, REACH, EU RoHS, China RoHS, WEEE |
| Networking | |
| Remote Management Interface | Ethernet 10/100/1000, USB |
| Environmental Parameters | |
| Min Operating Temperature | 23 °F |
| Max Operating Temperature | 113 °F |
| Humidity Range Operating | 5 - 95% RH (non-condensing) |
| Power Device | |
| Input Voltage | AC 207-253 V |
| Input Wiring | 1-phase |
| Frequency Required | 50/60 Hz |
| Input Connectors | 2 x power IEC 60309 32A |
| Power Output Connectors Details | 16 x power IEC 60320 C13 ¦ 2 x power IEC 60320 C19 |
| Output Voltage | AC 230 V |
| Max Electric Current | 32 A |
| Power Capacity | 7400 VA |
| Circuit Protection | Circuit breaker |
| Dimensions & Weight | |
| Width | 17 in |
| Depth | 9.3 in |
| Height | 3.5 in |
| Weight | 15.3 lbs |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 23 in |
| Shipping Depth | 14 in |
| Shipping Height | 8.3 in |
| Shipping Weight | 20.79 lbs |
